Angle Measurer PRO GAM 220 BOSCH

Angle Measurer PRO GAM 220 BOSCH Specification

Resistant Feature
Dust and splash-water resistant

Usage & Applications
Angle measurement for carpentry, construction, interior fitting

Accuracy
0.1

Batteries Type
4 x 1.5 V LR6 (AA)

Product Type
Angle Measurer

Material
Aluminium

Operating Temperature
-10C to +50C

Insulation Box
No

Protection System
IP54

Size
Up to 220

Color
Blue and Silver

Dimension (L*W*H)
1180 mm x 55 mm x 35 mm

Weight
1.1 kg

Measuring Range
0 - 220

Arm Length
40 cm

Data Hold Function
Yes

Automatic Shut-off
Yes, after 30 minutes

Storage Temperature
-20C to +70C

Display Type
Digital LCD

Memory Function
Yes

Laser Measurement
No

Measurement Units
Degrees

Power Supply
Batteries

Reference Angle Setting
Yes

Backlight Display
Yes

Carrying Case Included
Yes

Calibration Required
No

Angle Measurer PRO GAM 220 BOSCH Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Angle Measurer PRO GAM 220 BOSCH

The Bosch PRO GAM220 is a professionalgrade digital angle measurer designed for accurate and efficient measurement and transfer of angles on construction and woodworking projects. Featuring a clear and easytoread illuminated display, this tool allows users to quickly measure angles within a 0220 range with high precision and transfer them consistently onto workpieces using a mechanical locking screw. Its robust design and reliable performance make it ideal for use by craftsmen, installers, carpenters, and contractors.

Key Features

Fast & Precise Angle Measurement: Quickly calculates angle values for accurate project layouts.
Mechanical Locking Screw: Ensures stable and precise transfer of measured angles to workpieces.
Illuminated Display: Makes readings easy in various lighting conditions.
Automatic Shutoff: Conserves battery life with auto deactivate feature.
Robust Construction: Built for durability in daily professional use.

Technical Specifications

Model: Bosch PRO GAM220 (Order no. 0601076500)
Measurement Range: 0 220
Arm Length: 40cm
Measurement Accuracy (Angles): 0.1
Measurement Accuracy (Vials): 0.05
Battery: 41.5V LR6 (AA) (approx. 80h runtime)
Automatic Deactivation: 30min
Weight (approx.): 1.3kg

Applications

Angle measurement and layout in woodworking, carpentry, metalwork, tile fixing, and construction projects.
Transferring and setting complex angles for mitre cuts and installation alignments.

Robust Design and Reliable Accuracy

Crafted from durable aluminium, the Angle Measurer PRO GAM 220 BOSCH offers impressive protection against dust and splashes with its IP54 rating. It operates accurately in a wide temperature range, ensuring performance in varied on-site conditions. The digital LCD with backlight and user-friendly features like memory and data hold functions provide seamless measurement and data management.

Convenience and Usability on the Job Site

Equipped with a 40 cm arm and a measuring range up to 220 degrees, this tool is specifically suited for demanding professional environments. Its automatic shut-off function aids in conserving battery life, while the reference angle setting simplifies repetitive tasks. The inclusion of a carrying case adds portability, making it ideal for mobile professionals.

FAQ's of Angle Measurer PRO GAM 220 BOSCH:

Q: How does the automatic shut-off feature work on the Angle Measurer PRO GAM 220 BOSCH?

A: The automatic shut-off feature powers down the device after 30 minutes of inactivity, helping to conserve battery life and ensure the tool is ready for use during long workdays.

Q: What process should I follow to use the data hold and memory function?

A: To use the data hold function, simply press the designated 'Hold' button while taking a measurement. For memory storage, use the 'Memory' button to save current measurements for future recall. Both functions allow you to manage and reference important measurement data efficiently.

Q: Where can the Angle Measurer PRO GAM 220 BOSCH be effectively used?

A: This tool is ideal for use in carpentry, construction, interior fitting, and similar applications where precise angle measurement is required, especially on job sites where durability and reliability are essential.

Q: When is calibration required for this model?

A: The ANGLE MEASURER PRO GAM 220 BOSCH comes pre-calibrated and does not require user calibration, ensuring accurate results straight out of the box.

Q: What are the benefits of the digital LCD with backlight?

A: The digital LCD with backlight ensures that measurements can be read clearly in various lighting conditions, providing visibility in dim or bright environments alike.

Q: How does the IP54 protection benefit job site usage?

A: IP54-rated dust and splash-water resistance means the tool withstands harsh job site conditions, reducing the risk of damage from particles or moisture, and enhancing its longevity in demanding workplaces.
